WIRING-BATTERY
86037580 GLIDE 02/10/09
5-60
REF PART NO.
PRV
NO.
QTY DESCRIPTION
SERIAL NO.
FROM
NOTES:
1 86008920 80889 14 BOOT, RUBBER TERM. ISOLATOR
2 86232040 830957 1 CABLE, 4GA BLACK X 78.5”
3 86008790 80687 1 FUSE, 125 AMP
4 8606850 70393 2 SET SCR, 1/4-20 X 1.25L
5 86255910 73659 2 STANDOFF, 1/4-20 X 1.0 HEX INS
6 86279130 87083 4 WASHER, 5/16 SPLIT LOCK PLTD
7 86276780 70728 4 SCR, 5/16-18 X 3/4 HHCS SS
8 86069720 140497 1 BRACKET, BATTERY CONNECTOR
9 86273830 70020 2 SCR, 1/4-20 X 1/2 HHCS SS
10 86260310 82687 1
WIRE, 4 X 77BK C. TERM X 5/16
RING
11 86005810 57245 1 NUT, 1/4-20 HEX NYLOCK SS
12 86010630 87013 3 WASHER, 1/4ID X 5/8OD SS
13 86271910 57295 12 NUT, 5/16-18 FLEXLOCK
14 86009000 81131 5
WIRE, 4 X 9.5BK 5/16 RING X 5/16
RING
15 86260510 880377 1 WIRE, 4 X 6 BK C.TERM X 5/16 RING
16 86069690 140493 1 BRACKET, BATTERY
17 86064860 78498 1 TRAY, BATTERY
18 86001550 40043 1 HOSEBARB, 3/8 MPT X 3/8 90D
19 86233090 20016 1 CLAMP, 1/4ID HOSE
20 86281820 39509 1 HOSE, 3/8 VINYL X 16"
21 86002030 17298 1 CAP, .460ID X 1.5L BLK VINYL
22 86271830 57283 1 NUT, 3/8 NPT PLASTIC
23 86010860 880353 1
WIRE, 4 X 20 BK C.TERM X 5/16
RING
24 86010850 880352 1
WIRE, 4 X 27 RD C.TERM X 5/16
RING
25 86008760 80682 2
CONNECTOR, BATTERY GRY 175
AMP
26 86010670 87029 12 WASHER, 5/16 FLAT SS
27 86005710 57105 2 NUT, 1/4-20 HEX W/ STAR WASHER
28 86010780 87162 2 WASHER, 1/4 SPLIT LOCK
29 8623360 28038 1 CLAMP, CABLE KIT SY945
30 86270890 57034 1 NUT, ACORN 10-32
31 86010650 87018 1 WASHER, #10 X 9/16 OD
32 86273980 70066 1 SCR, 10-32 X 3/4 PPHMS SS
33 86312710 - 2 BLOCK, 3.5 X 4 X 5
FOR 86312720
BATTERIES
