BRAKE – TO SERIAL NUMBER *(7)
86037580 GLIDE 06/26/12
5-4
REF PART NO.
PRV
NO.
QTY DESCRIPTION
SERIAL NO.
FROM
NOTES:
1 86276880 70751 1 SCR, 1/4-20 X 3/8 HHCS SS
2 86278940 87008 1 WASHER, 1/4ID X 1-1/4OD PLTD
3 86255560 82855 1 SPRING, .31 X .04 X 3.0 EXT CS ZC
4 86279620 87200 2 WASHER, .4ID X 1.3OD NYLON
5 86355600 - 1 PAD, BRAKE PEDAL
6 86355540 - 1 PEDAL, BRAKE SRS
7 86008670 80606 3 COTTER, 3/8” RING
8 86248980 81438 1 PIN, CLEVIS 3/8” X 1.75 PLTD
9 86273810 70018 3 SCR, 1/4-20 X 1 HHCS SS
10 86010780 87162 2 WASHER, 1/4 SPLIT LOCK PLTD
11 86010630 87013 2 WASHER, 1/4ID X 5/8OD SS
12 86215650 29251 1 DISK, BRAKE
13 86005810 57245 3 NUT, 1/4-20 HEX NYLOCK SS
14 86073850 140466 1 CALIPER, CLOCKWISE BRAKE
14A 86135470 83050 1 CALIPER ACTUATING PIN SERVICE ONLY
14B 86134940 83051 1 BACKING PLATE, CALIPER SERVICE ONLY
14C 86135480 83052 1 PUCK CALIPER SERVICE ONLY
14D 86010330 83053 1 CALIPER, ANVIL SUB-ASSEMBLY SERVICE ONLY
15 86251790 67480 2 ROD END, BALL JOINT 1/4-28
16 86271600 57225 2 NUT, 1/4-28 HEX
17 86065800 05003 1 ARM, LOWER VAC CONTROL
18 86273820 70019 2 SCR, 1/4-20 X 1.25 HHCS
19 86254960 730266 1 SPRING, COMP .67 OD X 1.63 X .08
20 86066010 140458 1 ARM, BRAKE LEVER
21 86087430 73206 1 SPACER, 3/8OD X .058W X 1/2L CRS
22 86252040 67470 1 ROD, BRAKE PUSH
23 86078400 66356 1 PIN, CLEVIS 0.375 X 8.26L
24 86005860 57273 1 NUT, 1/4-20 X 12MM HEX BARREL
25 86276890 70752 1 SCR, 5/16-18 X 3/4 PTHMS SS
26 86077270 51367 1 LEVER, PARKING BRAKE
27 86004800 48030 1 KNOB
28 86006720 70245 2 SCR, 4-40 X 3/4 PPHMS
29 86028630 72082 1 SWITCH, SOL LEVER BENT
30 86271280 57163 2 NUT, 4-40 W/STAR WASHER
* SEE SERIAL NUMBER PAGE.
