SCRUB DECK-28 IN DISK
86037580 GLIDE 01/03/07
5-16
5-18
REF PART NO.
PRV
NO.
QTY DESCRIPTION
SERIAL NO.
FROM
NOTES:
1 86005250 53258 2 MOTOR ASM, 36V 330 RPM GEAR
1A 86001890 14418 REF BRUSH SET, MOTOR SERVICE ONLY
2 86279130 87083 2 WASHER, 5/16 SPLIT
3 86087940 730104 1 STRAP, REAR SQUEEGEE
4 86253910 730101 1 SKIRT, REAR
5 86276950 70772 10 SCR, 1/4-20 X 3/4 CARRIAGE SS
6 86093960 62962 1 SCRUB DECK, 28 SMALL RIDER
7 86276970 70774 8 SCR, 3/8-16 X 3/4 HHCS SS
8 86279530 87173 2
WASHER, .765 ID X 1.31 OD X .090 T
SS
9 86004810 48040 2 KEY, 1/4 SQ X 1.00
10 86003420 29220 2 DRIVER, BRUSH SD
11 86010790 87163 8 WASHER, 3/8 SPLIT LOCK
12 86007020 70673 2 SCR, 5/16-18 X 1.25 HHCS SS
13 86279630 87212 2 WASHER, .344ID X 1.13OD X .09T
14 86253900 730099 1 SKIRT, FRONT
15 86271830 57283 2 NUT, 3/8 NPT PLASTIC
16 86087930 730103 1 STRAP, FRONT SQUEEGEE
17 86005630 57022 3 NUT, 3/8-16 HEX NYLOCK THIN SS
18 86010890 89059 2 WHEEL, BUMPER
19 86276400 70642 1 SCR, 3/8-16 X 3 HHCS
20 86001550 40043 2 HOSEBARB, 3/8MPT X 3/8 90D
21 86003580 34327 1 FITTING, 1/8" X 3/8" X 3/8" RED
22 86009710 82312 1 VALVE, 36VDC SOL. 1/2" HOSEBARB
- 86003460 29260 - DIAPHRAGM SRVC PART SLND SERVICE ONLY
- 86136820 47395 - SOLENOID SPRING KIT SERVICE ONLY
23 86005810 57245 10 NUT, 1/4-20 HEX NYLOCK SS
24 86281480 39390 1 HOSE, 1/2 ID NYLOBRAID 14”
25 86280860 39053 2 HOSE, 3/8 NYLOBRAID X 7”
26 86282180 39613 1 HOSE, 1/2 ID NYLOBRAID X 17”
27 86233150 20042 1 CLAMP, 3/8 HOSE (D-SLOT)
28 86009200 81535 2 KNOB, 3/8-16 4 PRONG ALUM
29 86279620 87200 4 WASHER, .4 ID X 1.3 0D NYLON
30 86010770 87143 2 WASHER, 7/16 ID X 1 D X .08 FLT SS
31 86276920 70755 2 SCR, 3/8-16 X 1 HHCS SS NP
