SCRUB DECK LIFT-28 IN &32 IN
86037580 GLIDE 06/27/11
5-22
REF PART NO.
PRV
NO.
QTY DESCRIPTION
SERIAL NO.
FROM
NOTES:
1 86272600 80657 1 PIN, COTTER HAIR .148” DIA X 3/4 *(2)
2 86352950 - 1 ACTUATOR, 36VDC, 2.0 STROKE *(6)
3 86008670 80606 4 COTTER, 3/8” RING
4 86092250 29254 1 DECK LIFT ASM
5 86008720 80637 3 PIN, CLEVIS 3/8” X 2.375 PLTD
6 86090270 87204 2 WASHER, RECTANGULAR HOLE
7 86077470 51362 2 LINK, DECK LIFT
8 86254880 730005 1 SPRING, COMP 1.687OD X 4.5L X .234W
9 86001320 140353 2 BALL JOINT ASSY, 3/8-24 LH
10 86005830 57263 2 NUT, 3/8-24 UNF LH
11 86006440 67415 2 ROD, SCRUB LIFT
12 86005800 57217 2 NUT, 3/8-24 HEX JAM
13 86008810 80697 2 BALL JOINT ASSY, 3/8-24 RH
14 86276920 70755 6 SCR, 3/8-16 X 1 HHCS SS NP
15 86008460 80102 6 SPACER, .500OD X .391ID X .400
16 86271530 57216 4 NUT, 3/8-24 HEX NYLOCK
17 86009050 81324 6 BEARING, 1/2ID X 11/32L NYLON
18 86005630 57022 6 NUT, 3/8-16 HEX NYLOCK THIN SS
19 86077330 31373 2 LINKAGE, .25 X 1.25 X 9.25
20 86066790 140503 1 BAR, PANHARD
21 86248970 81406 2 PIN, CLEVIS 3/8 X 2
22 86276780 70728 1 SCR, 5-16-18 X 3/4 HHCS SS
23 86008550 80583 1 HORN, 36VDC
24 86270830 57023 1 NUT, 5/16-1/8 HEX NYLOCK SS
25 86005740 57112 2 NUT, 5/16-18 SERRATED FLG
26 86008740 80654 2 BUMPER, ADJUSTMENT
*SEE SERIAL NUMBER PAGE.
