SCRUB DECK-36 IN RETRACTABLE
86037580 GLIDE 01/03/07
5-28
5-30
REF PART NO.
PRV
NO.
QTY DESCRIPTION
SERIAL NO.
FROM
NOTES:
1 86005250 53258 1 MOTOR ASM, 36V 330 RPM GEAR
1A 86001890 14418 REF BRUSH SET, MOTOR SERVICE ONLY
2 86009550 82045 4 BEARING, 1.38 X .59 X .43 L SS
3 86093020 05165 2 LINKAGE, SWING
4 86009520 82035 2 SHAFT, DRIVER CYL. SCRUB
5 86228930 09145 4 BEARING, BALL 20MM X 37MM
6 86281440 39365 1 HOSE, 3/8 ID NYLOBRAID X 25”
7 86001550 40043 1 HOSEBARB, 3/8 MPT X 3/8 90 D
8 86277860 70787 1 SCR, 3/8-16 X 3.75 HHCS SS
9 86264920 27049 1 CABLE TIE, 7”
10 86010770 87143 2 WASHER, 7/16 ID X 1 D X .08 FLT SS
11 86279620 87200 1 WASHER, .41 D X 1.3 OD NYLON
12 86007670 73166 2 SNAP RING, EXTERNAL
13 86278360 70737 1 SHOULDER BOLT, 3/8 X 3/8 SS
14 86069540 140472 1 BRKT, SWING SKIRT CHANNEL
15 86007400 730095 1 SKIRT, SWING BLADE
16 86087910 730091 1 STRAP, SWING SKIRT
17 86276950 70772 3 SCR, 1/4-20 X 3/4 CARRIAGE
18 86010890 89059 3 WHEEL, BUMPER
19 86005810 57245 4 NUT, 1/4-20 HEX NYLOCK SS
20 86271830 57283 1 NUT, 3/8 NPT PLASTIC
21 86005630 57022 2 NUT, 3/8-16 HEX NYLOCK THIN SS
22 86276970 70774 4 SCR, 3/8-16 X 3/4 HNCS SS
23 86010790 87163 4 WASHER, 3/8 SPLIT LOCK
24 86007020 70673 1 SCR, 5/19-18 X 1.25 HHCS SS
25 86279130 87083 1 WASHER, 5/16 SPLIT LOCK PLTD
26 86279630 87212 1
WASHER, .344 ID X 1.12 OD X .09 T
PLT
27 86003420 29220 1 DRIVER, BRUSH SD
28 86279530 87173 1
WASHER, .765 ID X 1.31 OD X .09 T
SS
29 86274110 70094 1 SCR, 1/4-20 X 1/2 SHCS
30 86009200 81535 1 KNOB, 3/8-16 4 PRONG ALUM
31 86094490 730110 1 SWING, DECK ASM
32 86278870 80634 2 WASHER, 1.015 ID X 1.5 D X .055 T
33 86276470 70652 1 SCR, 3/8-16 X 2.25 HHCS SS
To Next Page
