Windsor Saber Glide SG28 Operator Instructions

SCRUB DECK SIDE SQUEEGEE-36 IN
86037580 GLIDE 01/03/07
5-32
REF PART NO.
PRV
NO.
QTY DESCRIPTION
SERIAL NO.
FROM
NOTES:
1 86005630 57022 2 NUT, 3/8-16 HEX NYLOCK THIN SS
2 86010890 89059 1 WHEEL, BUMPER
3 86274010 70070 1 SCR, 3/8-16 X 2 HHCS
4 86005810 57245 9 NUT, 1/4-20 HEX NYLOCK SS
5 86087860 62944 1 STRAP, SECONDARY SQUEEGEE
6 86276780 70728 2 SCR, 5/16-08 X 3/4 HHCS SS
7 86007550 730154 1 SQUEEGEE BLADE, SECONDARY
8 86069580 140478 1 BRKT, SECONDARY SQUEEGEE
9 86276960 70773 9 SCR, 1/4-20 X 1 CARRIAGE SS
10 86083740 730094 1 PLATE, SQUEEGEE LEFT
11 86270830 57023 6 NUT, 5/16-18 HEX NYLOCK SS
12 86082220 62934 1 PLATE, RIGHT SQUEEGEE
13 86065960 05162 4 ARM, SKIRT LINKAGE
14 86277090 70786 3 SCR, 5/16-18 X 3 HHMS FL THD SS
15 86242120 48090 3 KNOB, 1.0 OD X 5/16-18
16 86005650 57031 3 NUT, 5/16-18 HEX
17 86226810 73245 3 SPRING, COMP .72 X 2.0 L X .067 W
18 86277120 70792 2 SCR, 5/16-18 X 1.00 PFHMS SS
19 86087890 730089 2 STRAP, SIDE SQUEEGEE
20 86007390 730093 2 SQUEEGEE, SIDE BLADE LINATEX
21 86083730 730092 1 PLATE, SQUEEGEE RIGHT
22 86259410 87206 8 WASHER, THRUST .51 ID X 1 OD X .063
23 86279380 87146 16 WASHER 1/2 ID X 1 D X .08 NYL
24 86010670 87029 10 WASHER, 5/16 FLAT SS
25 86271840 57285 2 NUT, 5/16-18 HEX NYLOCK THIN SS
26 86228840 09124 8 BEARING, FLANGED .314 D X .502 OD
27 86007020 70673 6 SCR, 5/16-18 X 1.25 HHCS SS
28 86082200 62932 1 PLATE, LEFT SQUEEGEE
29 86272580 80638 4 PIN, CLEVIS 3/8 X 1.25 PLTD
30 86272380 66217 4 PIN, CLEVIS 3/8 X 3/4 PLTD
31 86226830 73268 4 SPRING, EXT .68D X 3.00L X .098W
