SCRUB DECK LIFT-36 IN
86037580 GLIDE 11/05/08
5-34
REF PART NO.
PRV
NO.
QTY DESCRIPTION
SERIAL NO.
FROM
NOTES:
1 86008720 80637 1 PIN, CLEVIS 3/8” X 2.375” PLTD
2 86014490 - 1 ACTUATOR, 36VDC 5.0 STRK SG36 *(3) WAS 86000830
3 86277860 70787 2 SCR, 3/8-16 X 3.75 HHCS SS
4 86275960 70570 2 SCR, 5/16-18 X 2.5 CARRIAGE GR5
5 86091720 140579 2 BRKT, ACTUATOR LIFT SRS
6 86093970 730111 1 SCRUB DECK, 36” MIN
7 86270830 57023 3 NUT, 5/16-18 HEX NYLOCK SS
8 86270880 57032 2 NUT, 3/8-16 SERRATED FLG
9 86001320 140353 2 BALL JOINT ASSY, 3/8-24 LH
10 86005830 57263 2 NUT, 3/8-24 UNF LH
11 86006440 67415 2 ROD, SCRUB LIFT
12 86005800 57217 2 NUT, 3/8-24 HEX JAM
13 86008810 80697 2 BALL JOINT ASSY, 3/8-24 RH
14 86276920 70755 4 SCR, 3/8-16 X 1 HHCS SS NP
15 86008460 80102 6 SPACER, .500OD X .391ID X .400
16 86271530 57216 4 NUT, 3/8-24 HEX NYLOCK
17 86009050 81324 6 BEARING, 1/2ID X 11/32L NYLON
18 86005630 57022 8 NUT, 3/8-16 HEX NYLOCK THIN SS
19 86077330 31373 2 LINKAGE, .25 X 1.25 X 9.25
20 86066780 140500 1 BAR, PANHARD
21 86009710 82312 1 VALVE, 36VDC SOL 1/2” HOSEBARB
- 86003460 29260 - DIAPHRAGM, SRVC PART SLND SERVICE ONLY
- 86004620 47295 - SOLENOID SPRING KIT SERVICE ONLY
22 86276760 70728 1 SCR, 5-16-18 X 3/4 HHCS SS
23 86008550 80583 1 HORN, 36VDC
24 86005740 57112 2 NUT, 5/16-1/8 SERRATED FLANGE
25 86008740 80654 2 BUMPER, ADJUSTMENT
26 86273780 70015 2 SCR, 1/4-20 X 3/4 HHCS SS NP
27 86005810 57245 2 NUT, 1/4-20 HEX NYLOCK SS
28 86008670 80606 1 COTTER, 3/8 RING
29 86255430 81311 2
SPRING, COMP 1.00 X 3.5 L X .135
W
30 86274010 70070 2 SCR, 3/8-16 X 2 HHCS
31 86254250 730163 2 SPACER, 1.0 OD X .391 ID X 1.13 L
32 86233150 20042 1 CLAMP, 3/8 HOSE
33 86282060 39563 1 HOSE, 1/2 ID NYLOBRAID X 21.5
34 86010730 87088 2 WASHER, 5/8 ID X 1.18 X .06 SS
*SEE SERIAL NUMBER PAGE.
