MAINTENANCE
86037580 GLIDE 01/03/07
4-1
1. Batteries
2. Battery Tray Drain Hose
3. Squeegee Adjustment
4. Side Squeegee Adjustment
5. Scrub Brushes
6. Vacuum Filter
7. Float Switch
8. Solution Strainer
14
6
7
8
15
2
9
12
10
5
4
13
9. Brake
10. Steering Chain Tensioner
11. Vacuum Motor
12. Brush Motor
13. Traction Motor
14. Fuse
15. Circuit Breaker
16. Squeegee Lift Actuator
17. Scrub Lift Actuator
1
3
11
16
17
