RESET / RETURN TO FACTORY DEFAULTS
6
ADVANCED SETTINGS
Connected Devices
This displays the name of each device currently connected wirelessly
to the Winegard ConnecT 2.0
+
.
Change Network Address
Change Administration Password
It is not necessary to change the administration password, however,
to change the password click on CHANGE PASSWORD to bring up
the new password screen. See figure 7. Enter the new password
into the area for both PASSWORD and RE-ENTER PASSWORD. The
password in each of these boxes must match.
Figure 7
To return to factory default, press the reset button located inside the SIM
card/LED cover plate on the left-hand side for 30 seconds.
If you are unable to gain access to the outside antenna, you may perform a
power cycle from the power switch. In order to do this, start with the power
switch in the off position. You will need to turn the switch on, wait 90
seconds and then turn off. Repeat 3 consecutive times. On the next power
on, the system will begin a reset.
Reset Button
SIM Card
4G LTE UNITS ONLY
LED
WARNING: DO NOT CHANGE THE NETWORK ADDRESS UNLESS
INSTRUCTED BY WINEGARD TECH SUPPORT. DOING SO MAY CAUSE
YOUR SYSTEM TO NOT FUNCTION PROPERLY.
NOTE: Do not use the existing WiFi password for the ADMINISTRATION PASSWORD.
WARNING: ALL CHANGES WILL BE LOST AND THE UNIT WILL RETURN
TO FACTORY DEFAULT SSID AND PASSWORD.
