Removing the Turret
Before you begin make sure the antenna is in the stowed position, and the
interface box is unplugged from power.
Disconnect the coax cable(s) from the base and
sheath cable from the vertical ports.
Remove the four screws from the cable cover.
Remove the cable cover.
Loosen and unclip the power coupler from the
internal power cable.
Unthread and remove the power/control cable
retaining nut. Do not lose the retaining nut.
Remove nuts securing coax ports at base and top
of turret, then push the ports into the turret.
1
3
3
4
2
