Pinch point (labeled)
FIGURE 2. Pinch points
Pinch point (labeled)
FIGURE 1. Dimensions of SK-SWM3
44″
34″
23.5″
24″
21″
1
Before Installing the Antenna
You have selected the Winegard
®
TRAV’LER
®
automatic multi-satellite TV antenna. The TRAV’LER antenna will deliver
the ability to view multiple satellites at the same time with unmatched signal strength, the lowest travel height on
the market, maximum HD capabilities and easy to use functionality—just like you get at home. This manual provides
important information on the installation and operation of your TRAV’LER antenna on an RV. Please take time to read
the manual in its entirety before installing or operating your antenna.
Follow the instructions on this side of the manual if installing the TRAV’LER DIRECTV SWM Slimline antenna. For
operation instructions, follow the instructions on the reverse side of the manual.
Specifications
Depending on location and receiver type, the following satellites can be accessed with the TRAV’LER DIRECTV SWM
Slimline antenna during automatic operation: 99°, 101°, 103°.
Safety Recommendations
Do not attempt to install this
system in the rain or under any wet
conditions. Moisture may affect
electronics and void your warranty.
Do not paint this antenna. Painting
the TRAV’LER antenna will void
your warranty.
Pay attention to the pinch points as
the antenna raises. The pinch points
should be labeled on the antenna
(see fig. 2).
Height of assembled unit: 9.75”
Width of assembled unit: 34”
Length of assembled unit: 44”
Width of mount base: 21”
Length of mount base: 24”
Unit Weight: 53 pounds
Shipping Weight: 74 pounds
