Marine Installation Manual 2021-08 5-13
5 Engine Automation
5.7 WinGD integrated digital expert
X72DF
5.7 WinGD integrated digital expert
The WinGD Integrated Digital Expert (WiDE) is a comprehensive system that
enables engine monitoring and assistance.
The WiDE is comprised of two main systems, which include the Data Collection
Monitoring (DCM) system and the Engine Diagnostic System (EDS). The DCM
collects large amounts of data from the engine’s on-board sensors and signals,
while the EDS analyses the data, as well as monitors the engine performance,
predicting component malfunctions and supporting the crew with live trouble-
shooting and diagnostics.
Figure 5-8 The WiDE system
5.7.1 Data collection and monitoring
WiDE uses the DCM unit to collect data from the engine and other ship systems.
This data is displayed and stored, both on board the ship and remotely. Using a
secure communication channel, DCM allows data to be sent to an external server
of the customer’s choice. All the data is stored for the engine lifetime and is ac-
cessible for the customer by a protected user account.
With the permission of the customer, DCM enables WinGD to review ship com-
pany data when required, allowing the first step towards remote support collab-
oration.
The DCM system is included in the standard engine scope.
Onshore / Online
Remote Services
WiDE
DCM
Collecting Data
EDS
Analyse & Predict
Support
SM-0496
