IB70 Motherboard User Manual
20
USB2
Internal USB2.0
2x4 Wafer, pitch 2.0mm
USB3
Internal USB2.0
2x4 Wafer, pitch 2.0mm
3V1
3.3V output
1x2 Wafer, pitch 2.0mm
5V1
5V output
1x2 Wafer, pitch 2.0mm
5V2
5V output
1x2 Wafer, pitch 2.0mm
12V1
12V output
1x2 Wafer, pitch 2.0mm
PANEL1
OSD membrane control
2x5 Wafer, pitch 2.0mm
SYS_FAN
SYS_FAN1
3P Wafer, pitch 2.54mm
