IB70 Motherboard User Manual
7
Hardware Installation
This chapter provides information on how to use
jumpers and connectors on the IB70 SBC
Motherboard. Be cautious while working with
these modules. Please carefully read the content
of this chapter in order to avoid any damages.
The sections include:
2.1 Memory Module Installation
2.2 I / O Equipment Installation
2.3 Jumpers and Connectors
2.4 Jumper Settings
2.5 Connectors and Pin Assignment
