IB70 Motherboard User Manual
64
3.2.3 Chipset Menu
Chipset Menu includes displays about PCI Express Settings,
►USB Configuration
Displays USB Configuration Settings
►PCI Express Configuration
BIOS
Setting
Description
Setting
Option
Effect
High
Precious
Timer
Allow to set up High Precious Timer
settings
Enabled/
Disabled
Enables/
Disables this
function
Restore AC
Power Loss
This function allows to set up booting
options after a power failure
Power on/
Power off
Boot
automatically
after a power
failure
Serial IRQ
Mode
When working with personal computer
hardware, installing and removing devices,
the system relies on interrupt requests.
Continuous
Allow user to
set up desired
IRQ Mode
