IB70 Motherboard User Manual
23
CPU_FAN1: CPU FAN
ATX12V1: DC-In
*Note: Pin 3 is not visible for user
Pin №
Name
Pin №
Name
1
GND
2
+12V
3
SENSE
Pin №
Name
Pin №
Name
1
+12V
2
GND
3*
GND
Pin1
