Winnebago ADVENTURER 2002 WFG35U User Manual

Copyright 2002 Winnebago Industries Inc.
CHASSIS GROUP (CONTINUED)
COMPONENT PARTS FOR HYDRAULIC LEVELING
100536-48-000
KEY PART NUMBER U/M DESCRIPTION VENDOR NO.
100536-31-700 EA HOSE - HYDRAULIC - 360" RAP4163
100536-31-701 EA HOSE - HYDRAULIC - 96" RAP5352
100536-39-700 EA HOSE - HYDRAULIC - 384" RAP4164
100536-48-700 EA HOSE - 146" RAP2443
A
B B
A
1
2
3
128571-03-000
KEY PART NUMBER U/M DESCRIPTION VENDOR NO.
1 100532-12-706 EA SWITCH - WARNING/MAGNETIC RAP1008 / RAP90496
2 100532-12-707 EA SPRING KIT R3847
3 100532-53-700 EA CYLINDER ASM. - 9K RAP90491/AP15891
131306-02-701 EA FOOT - 9K JACK RAP8464
