5.3 Power Port Definition
PIN NO.
Signal Name
1
+24V
2
GND
3
N.C
SHELL
F.G
Note ：
► Strictly prohibit unplug the cable while the printer is power on.
► Avoid paralleling with the strong current.
► you have to use the shielded communication line.
