Venting the integrated dosing equipment
16
13 Venting the integrated dosing equipment
INFO: The following working steps only apply to dosing equipment which is integrated when supplied from
the factory. If the dosing equipment is integrated into the machine during installation or is installed externally,
you must adhere to the respective device documents for the particular dosing equipment and the operating
instructions for the UC series.
Screen 04
¾ Press button (1).
D Screen 04 appears.
¾ Press the scroll button (2).
D Screen 04b appears.
Screen 04b
Screen 04c
¾ Press and hold button (3).
D o.
D The integrated detergent
dosing device is activated
(max. 30 seconds) and
vents.
¾ Press the scroll button (2).
D Screen 04c appears.
¾ Press and hold button (4).
D The background of the but-
ton turns white.
D The integrated rinse aid dos-
ing equipment is activated
(max. 30 seconds) and
vents.
¾ Set the dosing quantity using the service instructions (“Sinner circle” chapter).
Installation of the machine is now complete if the menu-driven installation procedure (chapters 11.1 to 11.8)
has been followed. Otherwise, continue as described in chapter 14.
