9 Troubleshooting
If the air heater malfunctions, first check if the problem is
caused by external circumstances (e.g. no supply power).
If the problem is not caused by external circumstances,
use the tables and instructions in this chapter to fix the air
heater.
NOTICE Please remember the built in waiting times of
the air heater; the signals of the LED’s and the code on the
display. Do not react too soon.
9.1 Volatile lock outs
The table below describes the volatile lock outs that can
occur. These can only be reset by hand.
Display Error type Description Case #
L-0 Internal error Internal error 13
L-1 Ignition error Flame lasts only 5 seconds
after ignition
1
No flame after ignition 2
L-2 and 3 Internal error Internal error 13
L-4 E-error E-error for more than 24
hours
12
L-8 to 12 Internal error Internal error 13
L-13 Pressure switch error Pressure switch is closed
in stand-by mode
14
L-14 Pressure switch error Pressure switch does not
close during pre-purge
11
L-15 Overheating Heat exchange sensor is
overheated
3
L-17 to 19 Internal error Internal error 13
L-20 Flame error Flame detected after
closing the gas valve
15
L-21 Flame error Flame detected before
closing the gas valve
16
L-22 Flame error Flame failure during
burning
5
L-25 Sensor error Heat exchange sensor
failure
4
L-27 to 31 Internal error Internal error 13
L-32 Sensor error Heat exchange sensor
failure
4
L-33 to 38 Internal error Internal error 13
L-43 Overheating Heat exchange sensor is
overheated too often
3
9.2 Temporary errors
The table below describes the temporary errors that can
occur. These will disappear automatically after the cause
has been resolved.
Display Error type Description Case #
E-00 to 04 Internal error Internal error 13
E-05 Overheating Heat exchange sensor is
overheated
3
E-06 to 13 Internal error Internal error
Flame detected when there
shouldn’t be one
13
E-14 Flame error 16
E-15 to 20 Internal error Internal error 13
E-21 and 22 Heat exchanger
sensor error
Heat exchanger sensor not
detected
4
E-27 and 28 Heat exchanger
sensor error
Heat exchanger sensor
short-circuit
4
E-34 Reset button
error
Too many reset actions in a
short timespan
9
E-36 Overheating Heat exchange sensor is
overheated
3
E-38 and 39 Heat exchanger
sensor error
Heat exchanger sensor not
detected
4
E-47 and 48 Heat exchanger
sensor error
Heat exchange sensor
short-circuit
4
E-49 to 64 Internal error Internal error 13
E-65 Voltage too low Supply voltage is too low
for over 1 minute
E-66 Voltage too high Supply voltage is too high
for over 1 minute
E-67 Pressure switch
error
Too many pressure switch
errors
11
E-69 Configuration
error
Heater configuration error 19
9.3 Warnings
The table below describes the temporary warnings that
can occur. The heater may still be working, or stops until
the cause has been resolved.
Display Error type Description Case #
A-02 Configuration
error
Heater configuration error 19
A-07 Overheating Heat exchange sensor is
almost overheated
3
