5INSTALLATION MANUAL AIR HEATER TYPE DXC
3 Technical specifications
3.1 Performance
Technical specification Unit Type DXC v4.1
DXC60 DXC80 DXC100
Net nominal heat input (max.) kW 65.5 83.0 108
Net nominal heat input (min.) kW 44.0 53.5 73.5
Heat output (max.) kW 59.9 75.9 99.1
Heat output (min.) kW 39.4 47.9 65.8
Eciency at max. power % 91.5 91.5 91.8
Eciency at min. power % 89.5 89.5 89.5
Air output (max.) m
3
/h 6000 8000 10,000
Throw horizontal (max.) m 40 45 50
Gas connection G” 3/4" 3/4" 3/4"
Electrical connection (50 Hz) V 230 230 230
Electrical power consumption kW 0.8 0.9 1.4
Stand-by electrical power
consumption
kW 0.004 0.004 0.004
Electrical current (max.) A 3.5 3.9 6.1
Protection class - IPX4D
NOx emission (GCV) mg/kWh 139 126 135
NOx class - 3 3 3
Flue gas amount (max.) kg/h 122 150 199
Chimney flue pressure (max.) Pa 25 40 60
Pressure switch point Pa 180 160 180
Thermostat connection - 2-wire low voltage communication bus or ON/OFF
Flue length (max.) m 9 9 9
Weight kg 140 150 175
