Instructions premix Air heaters type XR10.. 60 Page 13/15
Activities:
10.1 General inspection
• Check the overall condition of the installation. Check the heater, the thermostat, the wires
and the gas line.
10.2 Inspection of the heater
Before starting the inspection, switch off the electric power to the heater with the maintenance-
switch and close the manual gasvalve.
• Take out the burner, complete with flange and pre-mix fan, by unscrewing the 6 off M6
socket screws and you have taken off the ignition and fan wires
• Check the heatexchanger from the inside for dirt and/or damage.
• Check the burner on damage and clean the ignition electrode if necessary . CAUTION: do
not twist the electrode out of shape!
• Check the airsupply and the flue discharge.
• Clean eventual the inside of the heater with a vacuum cleaner.
• In case the heatexchanger is dirty on the outside, clean it with a soft brush. Never use a
steel wire brush!
• Clean the fan-grid with a vacuum cleaner and a brush.
• Put the burner back in (renew the gasket)
After this, check the heater on efficiency of combustion and adjust these if necessary
Check the heater operates correctly.
10.3 Spare parts
Description 10 20 30 40 50 60
Burner XR IX.3206 IX.3206 IX.3208 IX.3208 IX.3210 IX.3212
Ignition/Ionisation electrode IX.3458 IX.3458 IX.3458 IX.3458 IX.3458 IX.3458
Premix fan MVL RG128 (M2) IX.4500 IX.4500 IX.4500 IX.4500 IX.4500 IX.4500
Inspection glass IX.6812 IX.6812 IX.6812 IX.6812 IX.6812 IX.6812
Gas-AirMixer SIT 391 AGM IX.4506 IX.4504 IX.4502 - - -
Gascontrol SIT SIGMA 848 IX.3000 IX.3000 IX.3000 IX.3000 IX.3000 IX.3000
Burner control SIT DBC577 IX.3550 IX.3550 IX.3550 IX.3550 IX.3550 IX.3550
Fan Control DFC 100 GA.5706 GA.5708 GA.5710 GA.5712 GA.5714 GA.5716
Systemfan FMV (M1) IX.4200 IX.4200 IX.4200 IH.4206 IH.4206 IX.4205
NTC Cable sensor IX.3918 IX.3918 IX.3918 IX.3918 IX.3918 IX.3918
STB capillairy thermostat IX.3914 IX.3914 IX.3914 IX.3914 IX.3914 IX.3914
Transformer system fan IX.5100 IX.5100 IX.5100 IX.5098 IX.5098 IX.5098
Gasket ; inlet heatexchanger IX.6702 IX.6702 IX.6702 IX.6742 IX.6742 IX.6742
Gasket ; outlet heatexchanger IX.6708 IX.6708 IX.6708 IX.6744 IX.6744 IX.6744
Gasket ; premix fan IX.6704 IX.6704 IX.6704 IX.6704 IX.6704 IX.6704
Gasket ; ignition / ionisation electr IX.6710 IX.6710 IX.6710 IX.6710 IX.6710 IX.6710
Gasket ; inspection glass IX.6706 IX.6706 IX.6706 IX.6706 IX.6706 IX.6706
Burner isolation plate IX.6720 IX.6720 IX.6720 IX.6724 IX.6724 IX.6724
