09
Installation Diagrams | Wireless Joey: 6-TV Installation
Wireless Joey: 6-TV Installation
4 Wireless Joeys, 2 Wireless Joey Access Points, 2 Hopper with Slings, 1 Joey
ROOM 1 ROOM 2 ROOM 3 ROOM 4 ROOM 5 ROOM 6
(Bridging Enabled)
Wireless Joey
Access Point
Wireless Joey
Access Point
Duo Node
Hopper with Sling
H.I.C.
Satellite
950–2150 MHz
MoCA
650–875 MHz
Satellite and MoCA
650–3000 MHz
Cables
HDMI
Ethernet
Wireless
Router
MMTTVV-FMYYXXXXX
TO CLIENT TO CLIENT
EchoStar Technologies L.L.C.
Grounding wire size: Copper wire-8-14 AWG
Copper coated steel wire-17 AWG
T
O
L
N
B
F
S
DUO NODE
185836
TO HOST
10.5-28V
TO HOST
10.5-28V
pp g
Hopper with Sling
pp g
Wireless Joey
Wireless Joey
Wireless Joey
Wireless Joey
Terminator
