Page 40 Analyzer Q1 Witschi Electronic Ltd
Display
LCD graphic screen ¼ VGA (320 x 240 dots), monochrome blue/white, LED lighting.
The display can be tilted at an optimal viewing angle.
Working temperature
10° to 40°C.
Power supply
Plug-in power supply: 9 V~, 1.2 A.
Mains voltage: 230 V~ (210-240 V~), 115 V~ option (105 - 120 V~)
Dimensions
Width: 290 mm.
Height: 70 mm with folded display, 170 mm with swung-out display.
Depth: 170 mm (without plug).
Weight: 2.8 kg incl. mains adapter.
21 ACCESSORIES
Thermo printer with cutter (100-240V~) Item No. JB01-SLK-TE25-S
Thermo paper: roll Item No. JA01-MM60-740RS
Witschi GPS receiver, allowing synchronisation of time base Item No. 19.91PK1
and real time clock.
Autoprint: PC software for data transfer Item No. 64.55.901PK1
incl. link cable JB03-11.01.9018.
DECLARATION OF CONFORMITY
The equipment is in conformity with the following EC-Directives:
89/336/EWG CEM
Emissions
EN 55022 Conduction
EN 55022 Radiation
EN 60555-2 Harmonics
EN 60555-3 Flicker
Immunity
IEC 1000-4-2 ESD
IEC 1000-4-3 HF
IEC 1000-4-4 Burst
IEC 1000-4-5 Surge
IEC 1000-4-6 Cond. Immunity
IEC 1000-4-8 50Hz Magn. Puls
IEC 1000-4-11 Dips
