Witschi Electronic Ltd Analyzer Q1 Page 9
4.2 Place of Installation
Signal acquisition can be disturbed by electrical and magnetic stray
fields from electrical equipment. Computer terminals, fluorescent
lamps and ultrasonic cleaning equipment cause especially strong
interferences. It is therefore necessary to place the equipment far
enough from such interference sources. The influence of interfering
electromagnetic radiations may prevent the instrument of
functioning flawlessly.
4.3 Mains Connection
A mains adapter supplies ANALYZER Q1 with a 9 V~ output alternating voltage and a 1.2 A output
current. The mains adapter can be provided for a 230 V~ mains voltage (from 210 V~ to 240 V~) or
a 120 V~ mains voltage (from 110 V~ to 130 V~).
Before connecting for the first time, make sure that the voltage of the
mains adapter corresponds to the voltage of your mains.
Only use the original Witschi mains adapter!
Connect the mains adapter to the appropriate socket on the rear panel of the instrument.
We recommend disconnecting the mains adapter from the mains during longer idle periods, e.g.
vacations.
4.4 Printer Connection
Connect the printer available as an accessory, to the
printer
connector. The connecting cable is
delivered together with the printer.
Caution! Before connecting the printer, make sure that the voltage of its power supply
corresponds to the voltage of your mains.
4.5 Language
If the preset language or other system parameters do not correspond to your requirements, you can
modify them in the
System parameters
menu (see chapter 17.2)
