Deep cleaning
40 FB 7100 PLUS 10.2011
Cleaning the ingredient waste tray
• Remove and wipe clean the ingredient
waste tray with a clean and moist cloth
(fig. 31).
• Relocate the ingredient waste tray.
Cleaning the instant ingredient dis-
pensing system components
• Remove the mixing funnel hoods by lifting
off (fig. 32).
• Loosen locking rings of mixing funnels by
pressing release lever anti-clockwise and
pull out mixing funnel leaving hose back
on (fig. 32).
• Remove the sealing ring (fig. 33).
• Pull off the whipper wheel (fig. 33).
• Repeat procedure until all mixing funnels
have been removed.
31 32 33
