Deep cleaning
48 FB 7100 PLUS 10.2011
Cleaning inside and outside
• Clean the door and housing inside and
outside, and finally the bottom with a
clean, damp cloth (fig. 45).
• Flush all parts which have been soaking
thoroughly with clean and warm water.
• Dry all parts with a dry cloth.
Check that no dirt or cleaning
agent remains on the parts.
Mounting cleaned parts
• Remount all parts in reverse order.
• As to the freshbrew unit, see
“Reassembling the freshbrew unit” on
page 45
• Remount all canisters and push the outlet
tubes downwards to open the outlet
spouts of the canisters (fig. 46).
45 46
