Deep cleaning
10.2011 FB 7100 PLUS 41
Cleaning the powder trap
• Take hold of the small handle on the
powder trap and pull out (fig. 34).
• Separate front and rear parts (fig. 34).
• Soak both powder trap components in hot
water with cleaning agent.
• Rinse parts in clean hot water, dry and
relocate items in reverse order.
Cleaning the diffuser
• Remove brewer hose from diffuser (fig.
35).
• Remove the hood for diffuser and the
upper sealing ring (fig. 35).
• Turn the diffuser clockwise and pull it off
leaving the outlet hose back on (fig. 35).
• Remove the lower sealing ring.
The machine is fitted with a diffus-
er or a coffee mixer.
Cleaning the coffee mixer
• Remove brewer hose from diffuser (fig.
36).
• Remove the hood for diffuser and the
upper sealing ring (fig. 36).
• Turn the diffuser clockwise and pull it off
leaving the outlet hose back on (fig. 36).
• Pull off the whipper wheel (fig. 36) and the
lower sealing ring.
• Soak all removed parts in hot water with
cleaning agent.
34 35 36
