Wolf CSO24 - Convection Steam Oven Features

Installation Information
Convection Steam Oven (CSO24)
2-5
#821162 - Revision A - January, 2012
Flush Inset Installation
17
11
/16" (449)
OPENING
HEIGHT
18
3
/8"
(467) min
FLUSH INSET
HEIGHT
SIDE CLEATS
23" (584) min
FLUSH INSET
DEPTH
1" (25)
NOTES: Minimum base support 100 lbs (45 kg).
Electrical supply must be located in adjacent cabinet within 3'
(.9 m) of opening.
Cleats may be visible and should be finished to match cabinetry.
Dashed line represents profile of unit.
FRONT VIEWSIDE VIEW
TOP VIEW
22
1
/4" (565)
OPENING WIDTH
30
3
/8" (772) min
FLUSH INSET WIDTH
7
/16"(11) TOP CLEAT
1
/4" (6)
BOTTOM CLEAT
4
1
/16" (103)
SIDE CLEATS
EE
