13.2 Setting values appliance with Plus pcb
The below setting values are for a CWL -2-325-appliance with Plus pcb.
Step
No
Description Factory settings Setting range Comment
9 Switch contacts
9.1 Make or break contact 1 Make Make / Break
9.2 Switch contact control 1 Off Off
On
Meets Bypass conditions
Open bypass valve
Open external valve
9.3 Contact 1
Supply fan action
Fan off Fan off
Fan runs at absolute minimum
Fan at setting 1
Fan at setting 2
Fan at setting 3
Fan at step 0
Fan according to multiple switch
Fan runs at absolute maximum
No supply fan control
9.4 Contact 1
Exhaust fan action
Fan off Fan off
Fan runs at absolute minimum
Fan at setting 1
Fan at setting 2
Fan at setting 3
Fan at step 0
Fan according to multiple switch
Fan runs at absolute maximum
No exhaust fan control
9.5 Make or break contact 2 Make Make / Break
9.6 Switch contact control 2 Off Off
On
Meets Bypass conditions
Open bypass valve
Open external valve
9.7 Contact 2
Supply fan action
Fan off Fan off
Fan runs at absolute minimum
Fan at setting 1
Fan at setting 2
Fan at setting 3
Fan at step 0
Fan according to multiple switch
Fan runs at absolute maximum
No supply fan control
9.8 Contact 2
Exhaust fan action
Fan off Fan off
Fan runs at absolute minimum
Fan at setting 1
Fan at setting 2
Fan at setting 3
Fan at step 0
Fan according to multiple switch
Fan runs at absolute maximum
No exhaust fan control
10 0 - 10 V.
10.1 Mode input 1 Off On / Off
Setting values
xxxx
