Step
No
Description Factory settings Setting range Comment
10.2 minimum voltage
input 1
0V 0V / 10V Connector X-12
10.3 maximum voltage
input 1
10V 0V / 10V
10.4 Mode input 2 Off On / Off
10.5 minimum voltage
input 2
0V 0V / 10V Connector X-13
10.6 maximum voltage
input 2
10V 0V / 10V
11 Geo-heat exchanger
11.1 Switching on and off Off On / Off
11.2 Switch temperature 1 5 °C 0.0 °C / 10.0 °C
11.3 Switch temperature 2 25 °C 15.0°C / 40.0 °C
11.4 Mode valve 24 volt control Closed Open / Closed
11.5 Valve control Relay output 1 Relay output 1/
Relay output 2/
Analogue output 1/
Analogue output 2
Setting values
xxxx
50 | WOLF GmbH 7100833_202010
