SECTION 4 MAINTENANCE
This section lists the maintenance procedures that need to be performed.
CAUTION! Always disconnect and lock out power supply before
performing any maintenance work, cleaning or servicing the
Multi-Planer. Failure to do so may result in serious injury.
This symbol identifies the interval (hours of operation duty) at which each maintenance procedure
should be performed.
4.1 Wear life
See Table 4-1. Estimated life expectancy of common replacement parts is given in the table below.
This information is provided so that you may plan ahead in ordering replacement parts. This chart
lists estimated life expectancy of common replacement parts if proper maintenance and operation
procedures are followed. Due to many variables which exist during machine operation, actual part
life may vary significantly.
4.2 Sawdust Removal
Remove the excess sawdust and chips from the inside and outside of the Multi-Planer using
compressed air and a brush every eight hours of operation.
4.3 Miscellaneous Maintenance
1. Oil all chains with Dexron III ATF every fifty hours of operation.
CAUTION! Do not use chain lube. It causes sawdust buildup in chain
links.
2. Clean resin from the table. Use solvent if necessary. Lubricate the table, e.g. with paraffin oil.
3. Lubricate these parts every 50 hours of operation:
Feed roller bushing,
Sprockets,
Table height adjustment chain,
Part description Estimated
life
Drive belt 1250 hours
TABLE 4-1
