MULTI-PLANER SPECIFICATIONS
Multi-Planer Specifications
Specifications EGdoc052521 5-4
5
See table 5-4. USA motor specifications are given in the table below.
See table 5-5. Feed rate
See table 5-6. The noise level generated by Wood-Mizer Multi-Planer is given in the table below
1
2
3
MP180EA6U-V
Top Cutter Motor
Specifications
Side Cutter Motor
Specifications
Feed Motor
Specifications
Motor Type Electric Motor Electric Motor Electric Motor
Rated Voltage 1x230V 1x230V 1x230V
Rated Revolutions 2860 r.p.m. 2860 r.p.m. 1580 r.p.m.
Rated Power 2.7 kW 2.7 kW 0,18 kW
Wood-Mizer Part No. 533651-UL 533651-UL 532807-UL
TABLE 5-4
Multi-Planer Type Feed Rate
MP180EH6S
(Constant Feed Speed)
5 m/min
MP180EH7S-V
(Adjustable Feed Speed)
2-11 m/min
TABLE 5-5
Noise Level
MP180 Multi-Planer
equipped with electric motor
L
pA
= 86dB (A)
L
WA
= 104dB (A)
TABLE 5-6
1. The noise level measurement was taken in accordance with PN-EN ISO 3746 Standard . Value for associated
uncertainty K=4dB.
2. The measured values refer to emission levels, not necessarily to noise levels in the workplace. Although there is
a relation between emission levels and exposure levels, it is not possible to determine with certainty if preventives
are needed or are not needed. Factors that influence the actual level of exposure of the workforce include the
characteristics of the work room and the other sources of noise etc. i.e. the number of machines and other adjacent
processes. Also, the permissible exposure level value may vary depending on country. This information enables
the machine’s user to better identify hazards and a risk.
3. The total value of hand-arm vibration the operator may be exposed to does not exceed 2.5 m/s
2
. The highest
root mean square value of weighted acceleration to which the whole operator’s body is subjected does not exceed
0.5 m/s
2
.
