MULTI-PLANER SPECIFICATIONS
Multi-Planer Specifications
5
5-5 EGdoc052521 Specifications
IMPORTANT! The total value of hand-arm vibration the operator may be
exposed to does not exceed 2.5 m/s
2
. The highest root mean square value
of weighted acceleration to which the whole operator’s body is subjected
does not exceed 0.5 m/s
2.
See table 5-7. See the table below for planing/moulding material specifications
See table 5-8. Other specifications of the Multi-Planer are listed below.
Thicknessing Planing
Minimum Cant Height 10 mm
Maximum Cant Height 200 mm 80 mm
Cant Width 10-410 mm 10-300 mm
Maximum Thicknessing/Planing Depth 4 mm 6 mm
TABLE 5-7
Cutter Specifications
Number of knife sockets 2 or 4
Horizontal cutter diameter 72 mm
Horizontal cutter width 410 mm
Vertical cutter diameter 92 mm
Vertical cutter width 40 mm
Cutter rotations 5840 r.p.m.
Specifications of Knives
Straight knife height “A” 20 mm
Straight knife thickness “B” 3 mm
Straight knife protrusion “C” 1 mm
Pattern knife protrusion “C” depends on knife
thickness (see table 5-9)
TABLE 5-8
To Next Page
