MULTI-PLANER SPECIFICATIONS
Multi-Planer Specifications
Specifications EGdoc052521 5-6
5
See figure 5-2.
See table 5-9. A relation between the pattern knife protrusion and the thickness is shown below.
FIG. 5-2
Pattern knife thickness Pattern knife max.
protrusion
1
1
According to EN 847-1:2005 European Standard
3 mm 13 mm
4 mm 21 mm
5mm 29 mm
TABLE 5-9
