MULTI-PLANER SPECIFICATIONS
Multi-Planer Specifications
Specifications EGdoc052521 5-2
5
See table 5-1. The overall dimensions and weight of the MP180 machine are given in the table below.
5.2 Multi-Planer Specifications
See table 5-2. The Wood-Mizer Multi-Planer nomenclature is given in the table below.
See table 5-3. Europe motor specifications are given in the table below.
Machine type MP180
Weight 362 kg
Weight with transport box 440 kg
Height 1222 mm
Height (with optional wheels) 1315 mm
Width 954 mm
Length 1401 mm
TABLE 5-1
Volts
MP180EA6S 1 ph 230V CE
MP180EA6U 1 ph 230V UL
MP180EH6S 3 ph 400V CE
MP180EH7S 3 ph 400V CE
TABLE 5-2
MP180EA6S
Top Cutter Motor
Specifications
Side Cutter Motor
Specifications
Feed Motor
Specifications
Motor Type Electric Motor Electric Motor Electric Motor
Rated Voltage 1x230V 1x230V 1x230V
Rated Revolutions 2860 r.p.m. 2860 r.p.m. 1580 r.p.m.
Rated Power 2.7 kW 2.7 kW 0,18 kW
Wood-Mizer Part No. 533651 533651 533656
TABLE 5-3
MP180EB6S
Top Cutter Motor
Specifications
Side Cutter Motor
Specifications
Feed Motor Specifi-
cations
Motor Type Electric Motor Electric Motor Electric Motor
Rated Voltage 3x230V 3x230V 3x230V
TABLE 5-3
