Wood-mizer Simple Set SSW User Manual

Replacement Parts
Simple Set Kit, Complete (Standard)
2
2-2 SS09doc042913 Replacement Parts
14 Washer, 3/8” SAE Flat F05011-3 2
SSW-R Field Installed Kit Only (Includes parts above plus):
15 Bolt, 1/4-20 x 1/2” Hex Head F05005-15 4
16 Washer, 1/4” Split Lock F05011-14 4
17 Washer, 1/4” SAE Flat F05011-11 4
18 Nut, 1/4-20 Hex Nylon Lock F05010-69 4
19 Sheave, Modified AK64 x 5/8” 006874 1
20 Screw, #8-32 x 1” Flat Socket Head F05004-252 2
21 Bracket, Up/Down Motor Mount (Grove) 014073 1
22 Bracket, Up/Down Motor Mount (IPTS) 014529 1
23 Tie Wrap, 3/16” x 6” UV Black F05089-3 6
Instruction Sheet, Simple Set Retrofit SSW-1600 1
Manual, Simple Set Option M1610 1
1
Added to secure sensor cable away from moving up/down pulley (Rev. A.01).
