Wood-mizer Simple Set SSW - Troubleshooting & Settings Adjustment

Setup & Operation
Troubleshooting
Setup & Operation SS09doc042913 1-3
1
1.3 Troubleshooting
1.3.1 Error Messages
See Table 1-1. A description of Simple Set error messages is provided below.
Error Description
E02 Sensor This message is displayed if Simple Set cannot detect the
encoder sensor magnet when entering auto mode. Check
that the gear box extension is aligned with the sensor. Push
any button on the Simple Set control to exit to manual
mode.
E03 Sensor This message is displayed if Simple Set cannot detect a
signal from the encoder sensor when entering auto mode.
Check the encoder sensor cable connections. push any
button on the Simple Set control to exit to manual mode.
