Woods MAN0962 - Page 59

Parts 59
MAN0962 (1/9/2012)
STYLE - A WING & CENTER GEARBOX ASSEMBLY
REF QTY
Left Wing
540 & 1000
Right Wing
540 & 1000
Center
540 Only
Center
1000 Only
DESCRIPTION
A 1 1034900 1034899 1034901 1034902 Complete repair gearbox
1 1 1034903 **1034903 1034904 1034905 Gear crown
2 1 NS NS NS NS Gearbox housing
3 1 1034907 1034907 1034907 1034907 Input shaft
4 1 1034908 1034908 1034908 1034908 Output shaft
5 1 1034909 1034909 1034910 1034911 Gear pinion
6 2 1034906 1034906 1034906 1034906 Bearing cup & cone
7 2 1034912 1034912 1034912 1034912 Bearing cup & cone
8 1 1034913 1034913 1034913 1034913 Protector, seal
9 1 * * * * Cotter pin
10 2 1034914 1034914 1034914 1034914 Snap ring - internal 85 mm
11 1 1034915 1034915 1034915 1034915 Snap ring - external
12 1 1034916 1034916 1034916 1034916 Shim & gasket set
13 2 1034916 1034916 1034916 1034916 Shim & gasket set
14 1 1034917 1034917 1034917 1034917 Nut - hex slotted 1-3/8-18 UNEF
15 1 1034918 1034918 1034918 1034918 Castle nut M30 x 2.0P
16 1 1034916 1034916 1034916 1034916 Shim & gasket set
17 1 1034919 1034919 1034919 1034919 Spacer
18 1 1034920 1034920 1034920 1034920 Oil seal - output
19 1 1034921 1034921 1034921 1034921 Oil seal - input
20 1 1034922 1034922 1034922 1034922 Cap, blank
22 1 1034923 1034923 1034923 1034923 Cover, inspection
23 8 * * * * Hex cap screw, M8 - 1.25P x 25 mm
24 1 1034924 1034924 1034924 1034924 plug - relief, 1/2-14 NPT
25 1 * * * * Cotter pin
27 1 1034925 1034925 1034925 1034925 Gearbox repair kit (Includes items 6,
7, 8, 10, 11, 12, 13, 18 & 19)
28 12 * * * * Lockwasher, 8 mm split
29 4 * * * * Hex cap screw, M8 - 1.25P x 30 mm
30 1 1034926 1034926 1034926 1034926 Oil site gage A10
31 1 NS NS NS NS O-ring, 14 mm x 3 mm
32 1 1034986 1034986 1034986 1034986 Spacer, input
33 1 1034945 1034945 1034945 1034945 Snap ring - internal, 90 mm
* *
Crown gear placed on opposite
end of input shaft for right wing
* Standard hardware, obtain locally
NS Not Serviced
