OPER ATOR'S MANUAL

BATWING-

ROTARY CUTTER

(04/10/2018)

®

BW15.50E BW15.60E BW15.70E

BW15.50QE BW15.60QE BW15.70QE

BW10.50E BW10.60E BW10.70E

BW10.50QE BW10.60QE BW10.70QE

MAN1246

Table of Contents

Questions and Answers:

T
Thomas Lawson Jr.Aug 20, 2025
Why my Woods Farm Equipment does not cut?
- L
  Lauren RobinsonAug 20, 2025
  Your Woods Farm Equipment might not be cutting due to several reasons: * **Dull blades:** Sharpen the blades. * **Worn or broken blades:** Replace the blades in pairs. * **Incorrect PTO speed:** Set the equipment at the rated PTO speed. * **Ground speed too fast:** Reduce the ground speed. * **Drive not functioning:** Check the drive shaft connection. * **Gearbox malfunction:** Check the gearbox. * **Excessive clutch slippage:** Adjust the clutch. * **Incorrect blade direction:** Ensure the blade edge is correct for the direction of rotation.
D
Debra JamesAug 22, 2025
What to do if my Woods Farm Equipment creates streaks or ragged cuts?
- G
  Gregory JordanAug 22, 2025
  If your Woods Farm Equipment is leaving streaks or ragged cuts, consider the following: * **Broken or worn blades:** Replace or sharpen the blades. * **Incorrect attitude:** Level the machine. * **Ground speed too fast:** Reduce the ground speed. * **Excessive cutting height:** Lower the cutting height, ensuring blades don't frequently hit the ground. * **Excessive lush and tall vegetation:** Re-cut at 90° to the first pass.
M
mmillerAug 25, 2025
Why is there excessive clutch slippage in my Woods Farm Equipment?
- E
  ellispamelaAug 25, 2025
  Excessive clutch slippage in your Woods Farm Equipment can occur due to: * **Clutch out of adjustment:** Adjust the clutch. * **Worn clutch discs:** Replace the discs if the wear stops contacting the opposite plate. * **Blades hitting the ground:** Raise the cutting height.
B
Brenda BanksAug 26, 2025
What causes vibration in Woods Farm Equipment?
- N
  Nicole StevensonAug 27, 2025
  Vibration in your Woods Farm Equipment could be attributed to: * **Broken blade:** Replace blades in pairs. * **Bearing failure:** Check gearbox shafts for side play. * **Incorrect hitch length:** Reset the hitch length. * **Universal drive:** Adjust the pedestal bearing height to be parallel to the ground.
A
Anthony JensenAug 28, 2025
Why Woods Farm Equipment unit doesn’t cut level?
- S
  Shannon BrownAug 28, 2025
  If your Woods Farm Equipment isn't cutting level: * **Wing section cuts lower than center:** Lengthen the turnbuckle connecting the center yoke to the wing wheel yoke. * **Wing section cuts higher than center:** Shorten the turnbuckle connecting the center yoke to the wing wheel yoke.
J
Jessica SwansonAug 30, 2025
What to do if blades are hitting the deck on my Woods Farm Equipment?
- G
  Gary WilkersonAug 30, 2025
  If the blades are hitting the deck on your Woods Farm Equipment, it's likely due to bent blades or a bent crossbar. Replace the bent blades or crossbar to resolve this issue.
R
Rhonda MartinezSep 1, 2025
Why won't my Woods Farm Equipment unit raise?
- E
  Erik Cochran DVMSep 1, 2025
  If your Woods Farm Equipment unit will not raise, it may be due to low oil. Add hydraulic oil.
B
bmooreSep 3, 2025
What causes excessive side skid wear on Woods Farm Equipment?
- T
  theresa11Sep 3, 2025
  Excessive side skid wear on your Woods Farm Equipment is caused by running with the skids continuously on the ground. Raise the cutting height or adjust the equipment to prevent this.
B
brandon57Sep 5, 2025
What to do if Woods Cutter does not cut?
- J
  Jacqueline FordSep 5, 2025
  If your Woods Cutter blades are not turning when the PTO is running, check the drive shaft connection. Ensure the PTO speed is set to the rated speed. Also, verify the blade edge is correct for the direction of rotation. Other possible causes include dull, worn, or broken blades (sharpen or replace them), incorrect blade direction, gearbox malfunction (check gearbox), excessive clutch slippage (adjust clutch), or ground speed too fast (reduce ground speed).
D
davislisaSep 7, 2025
Why Woods Cutter leaves streaks or ragged cut?
- N
  Nicole ChavezSep 7, 2025
  Streaks or a ragged cut from your Woods Cutter can result from broken or worn blades (replace or sharpen them). It may also happen if the attitude is incorrect (level the machine), the ground speed is too fast (reduce ground speed), the cutting height is too high (lower cutting height), or the vegetation is too lush and tall (re-cut at 90° to the first pass).

Woods Batwing BW15.50E Specifications

General

Brand	Woods
Model	Batwing BW15.50E
Category	Cutter
Language	English

Summary

Specifications and General Information

Specifications

Technical data and dimensions for different Batwing models.

General Information

Overview of the manual's purpose and machine variations.

Safety Information

Safety Rules

Comprehensive safety guidelines for operation, maintenance, and transport.

Safety and Instructional Decals

Identification and location of safety decals on the equipment.

Operation Guide

Connecting Cutter and Tractor Operation

Procedures for connecting the cutter, tractor operation, and hydraulic setup.

Cutter Operation and Adjustments

Guidelines for mowing, shredding, cutting height, and operation tips.

Transporting, Lock-Up and Storage

Safe methods for transporting, securing, and storing the rotary cutter.

Pre-Operation Checklist

Owner's pre-use inspection checklist for safe operation.

Owner Service and Maintenance

Owner Service Procedures

Maintenance tasks like lubrication, blade service, and slip clutch adjustment.

Blocking Method and Tire Safety

Safety procedures for blocking the cutter and servicing tires.

Cleaning and Troubleshooting

Instructions for cleaning the unit and resolving common issues.

Dealer Service and Assembly

Dealer Service Procedures

Repair and maintenance for gearboxes, crossbars, and universal joints.

Assembly Instructions

Steps for dealers to assemble and set up the cutter for customers.

Dealer Check Lists

Checklists for pre-delivery and delivery procedures.

Reference Materials

Parts Index

Index of all parts and their corresponding page numbers.

Bolt Torque and Size Charts

Reference tables for fastener torque and size specifications.

Warranty Information

Details on product warranty coverage and terms.
