Woods Batwing BW15.50E - Specifications and General Information; Specifications; General Information

4 Introduction
MAN1246 (04/10/2018)
SPECIFICATIONS
BW15.50E / BW15.50QE BW10.50E / BW10.50QE
BW15.60E / BW15.60QE BW10.60E / BW10.60QE
BW15.70E / BW15.70QE BW10.70E / BW10.70QE
Cutting Height (Varies with tire selection) . . . . . . . . . . . . . . . . . . . . . . . . . . .25 mm - 380 mm 25 mm - 380 mm
Cutting Width . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4.5 m 3.2 m
Overall Width. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4.8 m 3.5 m
Transport Width . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2.4 m 2.3 m
Transport Height . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2.1 - 2.7 m 2.1 - 2.7 m
Tractor HP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 200 200
Tractor Min. PTO hp . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45 45
Tractor PTO rpm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .540/1000 540/1000
Blade Spindle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 2
Blade Overlap . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .152 mm 152 mm
Number of Blades . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 4
Blade Rotation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Left Spindle: CW; Right & Center Spindles: CCW
Blade Speed (meters per minute) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4572/4877 4572/4877
Wing Driveline . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Cat 4 Cat 4
CV Driveline. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Cat 6 Cat 6
Side Frame Thickness. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6.4 mm 6.4 mm
Wheel Size . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 737 mm Max
Torsion Protection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Slip Clutch Slip Clutch
WEIGHT SPECIFICATIONS
GENERAL INFORMATION
 Some illustrations in this manual show the equipment with
safety shields removed to provide a better view. This equipment
should never be operated with any necessary safety shielding
removed.
The purpose of this manual is to assist you in operating and main-
taining your cutter. Read it carefully. It furnishes information and
instructions that will help you achieve years of dependable perfor-
mance. These instructions have been compiled from extensive field
experience and engineering data. Some information may be general
in nature due to unknown and varying operating conditions. However,
through experience and these instructions, you should be able to
develop procedures suitable to your particular situation.
The illustrations and data used in this manual were current at the
time of printing but, due to possible inline production changes, your
machine may vary slightly in detail. We reserve the right to redesign
and change the machines as may be necessary without notification.
Throughout this manual, references are made to right and left direc-
tions. These are determined by standing behind the equipment fac-
ing the direction of forward travel. Blade rotation is clockwise (left
wing) and anticlockwise (right wing and centre section) as viewed
from the top of the cutter.
Model No.
Weight
(approximate kg.)
Tongue Weight
(approximate kg.)
BW15.50E / 15.50QE 1970 545
BW15.60E / 15.60QE 2020 612
BW15.70E / 15.70QE 2195 667
BW10.50E / BW10.50QE 1875 545
BW10.60E / BW10.60QE 1948 612
BW10.70E / BW10.70QE 2116 667
WARNING
