Worcester Greenstar 9i System ErP User Manual

8
Controls
Greenstar i System
ErP
– 6 720 806 947 (2015/03)
3.1 Appliance controls
Fig. 2 Display (example in standby with Eco mode active) and buttons
[1] Display Screen
[2] Eco mode active display message
[3] User function buttons:
•Eco button ( )
– Manually select Economy or Pre-Heat mode
• Info button ( )
– Access to Info menu Function
• Reset button ( )
– Appliance reset button
[4] Menu functions buttons:
•OK button ( )
–Confirms a selection
•Back button ( )
– To return to the previous option or menu
[5] Engineer function buttons:
• Spanner button ( )
– Service menu function button only
• Chimney sweep button ( )
– Engineer service and set up function only
[6] Central heating flow temperature adjustment buttons:
• Increase button ( )
–Increase value
•Decrease button ( )
– Decrease value
[7] Cylinder hot water maximum temperature adjustment
buttons, this function is only available if the optional
integral diveter valve kit is fitted. (These buttons are also
used in menu /scroll/adjustment, indicated by arrows on
right of text display line):
• Increase button ( )
–Increase value
•Decrease button ( )
– Decrease value
6720806946-02.1Wo
Eco
4
6
1
2
7
3
5
