XI. EXHAUST DIVERTER
If you purchased the optional Exhaust Diverter, you can re-direct the exhaust
flow backwards toward the GO-A8's tires (instead of forward toward the Gate
being opened). See Section XVI for ordering information.
To install the Exhaust Diverter:
1. Pivot the Wheels to the Straight position (parallel with wrench).
2. Disconnect the air supply line to the Gate Opener.
3. Tilt the Opener back onto the Foot Bar.
4. Dab the threads of the bolt provided with the Loc-tite provided.
5. Attach the Exhaust Diverter to the Impactor along its exhaust port.
The edge of the Diverter should butt-up against the top of the
exhaust port. See Figure 7 for Exhaust Diverter positioning.
Figure 7: Exhaust Diverter Positioning
