XV. REASSEMBLING THE IMPACTOR
Once the Impactor's internal components have been inspected, repaired or
replaced, the Impactor can be reassembled. The reassembly of the Impactor is
essentially the disassembly instructions in reverse order.
1. Wash all parts thoroughly in fresh, clean solvent.
2. Replace REAR PACKING (43) and FRONT PACKING (44).
3. Coat all parts with a light film of spindle oil or air tool oil.
4. Clean and repack, with a good grade of grease, two [2] BALL
BEARINGS (69) and CONE ROLLER BEARING (70)
5. Be sure all air passages are free of any dirt or foreign matter.
6. Grease the IMPACT MECHANISM (30 to 38) sparingly with a
high-grade Impact Wrench Grease (SHELL's Alvania EP 2, or Equal).
Refer to Appendix A: Exploded View during
reassembly
IMPORTANT
The outer surface of the Impact Mechanism is not
a bearing surface and should not be greased. If
too much grease accumulates between the Impact
Mechanism and the Hammer Casing (29), the
action of the unit will be impaired. Cold
temperatures compound the situation.
IMPORTANT
