3
IV. SPECIFICATIONS AND COMPONENTS
To operate to GO-A8-PW effectively the user should be familiar with each of
the Gate Opener's components. See Figure 1 for a Component layout, and
Appendix A for a breakdown of the Impactor and the list of Part Numbers.
The GO-A8 Pneumatic Hopper Car Gate Opener consists of a heavy-duty
reversible impact motor, self-closing lever control mechanism and a Rolling Cart.
The GO-A8 Opener is portable, rugged and capable of operating in the toughest
environment. Under recommended operating conditions and with regular
maintenance, the GO-A8 Opener can generate up to 13000 ft./lbs. torque. The
Impact Motor is air driven and requires a source of clean, dry compressed air for
operation.
Every user should be aware of the technical specifications and operating
characteristics shown below in Table 1.
Table 1: Technical Specifications
CHARACTERISTICS GO-A8-PW
Length 33"
Width 42"
Height 45"
Weight 308 Lbs
Working Area Required 8 – 10 Ft Minimum – Site Specific
Free Speed 1500 RPM
Working Torque Range 1000 – 13000 Ft/Lbs
CFM/PSI Free Speed 150 @ 85 PSI
CFM/PSI Impacting 114 @ 85 PSI
Air Inlet 1" NPTF
Tire Size 400 x 8 Solid Polyurethane
Anvil Size 1-1/2"
Retainer Type Socket Pin w/ O-Ring
Hose Size 1" ID
Lubrication Air Tool Oil
