A - 2
PARTS LIST
Item
#
Part# Description Qty
Item
#
Part# Description Qty
1 33-20100 Head Handle 1 34 33-20131 Hammer Cage Bushing 1
2 33-20101 Head Cover 1 35 33-20132 Anvil Front Spacer 1
3 33-20102 Reverse Valve 1 36 33-20133 Anvil Bushing 1
4 33-20103 Reverse Valve Bushing 1 37 33-20158 Exhaust Deflector 1
5 33-20104 Reverse Lever 1 38 33-20134 Eyebolt 1
6 33-20160 Reverse Valve Spacer 1 41 33-20161 Handle Gasket 1
7 33-20105 Reverse Valve Cover 1 42 33-20135 Rear Packing 1
8 33-20106 Reverse Lever Set Screw 1 43 33-20136 Front Packing 2
9 33-20107 Valve Body 1 44 33-20138 Allen Head Bolt 4
10 33-20108 Valve 1 45 33-20139 Half-Head Bolt 6
11 33-20109 Throttle Trigger 1 46 33-20140 Half-Head Bolt 8
12 33-20110 Valve Packing Spacer 1 47 33-20141 Round Head Screw 1
14 33-20111 Regulator Valve Cover 1 48 33-20146 Allen Head Set Screw 1
16 33-20113 Valve Ring Casing 1 49 33-20144 Hex Nut 14
18 33-20114 Valve Body Pipe 1 50 33-20142 Spring Washer 4
19 33-20116 Valve Body Nut 1 51 33-20143 Spring Washer 14
20 33-20122 Separator 1 52 33-20159 Tapping Screw 4
21 33-20117 Casing 1 53 33-20151 Allen Head Plug 1
22 33-20118 Cylinder Plate 2 55 33-20149 Roll Pin 1
23 33-20119 Cylinder 1 56 33-20150 Roll Pin 2
24 33-20120 Rotor 1 57 33-20148 Roll Pin 1
25 33-20121 Rotor Blade 9 59 33-20145 Spring 1
26 33-20123 Hammer Casing 1 61 33-20147 Cone Spring 1
27 33-20124 Anvil Rear Spacer 1 62 33-20152 Round Head Notch 1
28 33-20125 Hammer Cam 1 63 33-20153 Steel Ball 1
29 33-20126 Hammer Cage 1 64 33-20154 Ball Bearing 2
30 33-20127 Hammer 2 65 33-20155 Cone Roller Bearing 1
31 33-20128 Hammer Pin 2 66 33-20156 O-Ring 1
32 33-20129 Pilot Pin 1 67 33-20157 O-Ring 1
33 33-20130 Anvil 1 68 33-20137 Packing 1
Part # Description Includes
32-50010 Rebuild Kit #25, #42, #43
32-50012 Head Cover Assembly
#1-8, #41, #44, #50, #53,
#55, #59, #63, #67
32-50015 Throttle Valve Assembly
#9-12, #14, #16, #18, #19,
#47, #57, #61, #66, #68
32-50014 U-Joint Lever Assembly
#5, #8, #59, #63, plus F/R
Swivel Joint (not shown)
