WARNING!
Risk of injury when cutting narrow workpieces!
− Be absolutely sure to use the push stick when performing
lengthwise cuts for workpieces with a width of under 120mm.
One push stick is included in the product contents. Promptly
replace a worn or damaged push stick.
− When performing lengthwise cuts in very narrow workpieces
with a width of under 30mm, be absolutely sure to use a push
stick and set the parallel guide to low.
The push stick is not included in the product contents! You can purchase one at a rele-
vant supply store. Replace a push stick that is worn in due time.
Performing bevel cuts
In general, you should use the parallel guide
13
when performing bevel cuts.
1. Set the saw blade to the desired angle (see section “Setting the angle”).
2. Set the parallel guide corresponding to the width and height of the workpiece
(see section “Parallel guide”).
3. Perform the cut corresponding to the width of the workpiece (see section
“Performing lengthwise cuts”).
Performing cross cuts
1. Set the cross guide
19
as necessary (see section “Cross guide”). If the saw blade is
also to be set at an angle, push the cross guide into the right groove that prevents
your hand and the cross guide from coming into contact with the protective hood
17
.
2. Use the stop rail
14
if applicable.
3. Lower the protective hood
17
onto the saw table.
The protective hood is pushed up by the workpiece while sawing.
4. Firmly push the workpiece against the cross guide.
5. Switch on the dust collector first and then the saw.
6. Push the cross guide and the workpiece towards the saw blade to perform the cut.
