Technical data
Model: WZTS 1702
Supply voltage: 230 – 240 V, ~ 50 Hz
Output: S6 40% 1700 W
Idle speed n
0
: 6500 min
-1
Hard metal saw blade: Ø 250 x Ø 30 x 2.4 mm
24 teeth
Max. cutting depth: 72 mm / 90°
54 mm / 45°
Height adjustment: continuously 0 to 72 mm
Saw blade pivotable: continuously 0° – 45°
Extractor connection: Ø 36 mm
Net weight: approx. 24.5 kg
Sound pressure level L
pA
: 93.32 dB(A)
Uncertainty K
pA
: 3 dB
Sound power level L
WA
: 106.32 dB(A)
Uncertainty K
WA
: 3 dB
Dimensions:
Working height: 895 mm
Table size: 610 x 445 mm
Table width extension: 608 x 250 mm
Table length extension: 435 x 320 mm
Article number: 92534
S6 type of operation: Continuous operation
To prevent the motor from heating up to an impermissible extent, the table saw may
only be used as follows:
After being operated for a period of 4 minutes (S 6 = 40%) under a normal permissi-
ble load, the circular saw must be left in idle operation for 6 minutes.
