Transmitter Operations
Transmitter Overview & Binding to the Recon Drone
Code Binding Drone to Transmitter
The drone has already been binded to the transmitter included by default. The
following code binding is not necessary unless the drone is going to be controlled
with a new transmitter or if your current transmitter is having trouble connecting.
1. Turn on the drone and press the button underneath the gimbal to start binding.
2. Turn on the transmitter and hold the
and at the same time until the
screen displays “Binding ID=XXXX”.
3. The transmitter will connect with the drone when the screen enters the control
interface.
ON
OFF
TAKE OFF (press once)
ORBIT (press & hold)
HOVER LAND (press once)
RETURN HOME (press & hold)
ON/OFF
LCD Screen
Smartphone Cradle
Gimbal Pitch
Gimbal Yaw
ON
OFF
1 2
Binding..
Connecting...
ID=XXXX
...............
Initialized
00.0m 00.0m
00:00:00
16
Activate Rotors
(Hold for 3 seconds)
To Next Page
Loading...
