20V 2-in-1 Grass Trimmer/Edger
EN
1110
* Not all the accessories illustrated or
described are included in standard delivery.
TECHNICAL DATA
WG163E
WG163E.1
WG163E.2 WG163E.9
Voltage
20V
MAX**
No load
speed
7600/min
Cutting
diameter
30cm
Line
diameter
1.65mm
Charging
time
5hr 1 hr /
Machine
weight
2.4kg 2kg
**Voltage measured without workload. Initial battery
voltage reaches maximum of 20 volts. Nominal
voltage is 18 volts.
ACCESSORIES
WG163E WG163E.1 WG163E.2
WG163E.9
Flower
guard
1 1 1
1
Charger
1
(WA3760)
1
(WA3760)
1
(WA3880)
/
Battery
pack
2
(WA3551.1)
1
(WA3551)
1
(WA3551)
/
Spool
(WA0004)
1 1 1
1
Safety
guard
1 1 1
1
Edger
wheel
1 1 1
1
We recommend that you purchase your accessories
from the same store that sold you the tool. Refer to
the accessory packaging for further details. Store
personnel can assist you and offer advice.
ASSEMBLY AND OPERATION
NOTE: Before using the tool, read the
instruction book carefully.
Intended Use
The machine is intended for the cutting of grass and
weeds under bushes, as well as on slopes and edges
that can not be reached with the lawn mower.
WARNING! The charger and battery pack are
specially designed to work together so do not
attempt to use any other devices. Never insert or
allow metallic objects into your charger or battery
pack connections because of an electrical failure and
hazard will occur.
WARNING! Always wear the eye protection.
Never lean over the trimmer head. Rocks or
debris can ricochet or be thrown into eyes and face
and cause blindness or other serious injury. When
operating unit, check for the following:
Wear eye protection and heavy clothing. Hold front
handle with one hand and auxiliary handle with
the other hand. Keep unit below waist level. Work
only from your right to your left to ensure debris is
thrown away from you. Without bending over, keep
line near and parallel to the ground (perpendicular
when edging) and not crowded into material being
cut.
WARNING! Make sure that line is fed out
before operation. Make sure motor is up
to full speed before trimming or edging.
1. LOCK OFF BUTTON
2. REAR HANDLE
3. ON/OFF SWITCH
4. BATTERY PACK *
5. HANDLE UNLOCK BUTTON
6. UPPER SHAFT
7. LOCKING COLLAR
8. LOWER SHAFT
9. SAFETY GUARD
10. FLOWER GUARD
11. AUXILIARY HANDLE
12. COMMAND FEED BUTTON
13. EDGER WHEEL
14. LINE FEED BUTTON
15. LINE CUTTER
